ChinaCNCzone New 6090 CNC Router 4 Axis with Updated Water Sink Cool System and DSP Mach3 USB CNC Controller for Selection,Price Competitive.
- Shape dimension X890mm*Y1250mm*Z670mm
- Max.workpiece dimension X600mm*Y900mm*Z150mm
- Acceptable material thickness ≤150mm
- Spindle motor brand new 1500W, 2.2kw water cooling spindle, 24000RPM
- Spindle collet ER16-A, 3-10 mm shank diameter tool
- Repeat accuracy <=0.05mm
- Maximum speed 4000mm/min
- Carving speed 0-2500mm/min (different materials differ)
- Command code G code
- Software Mach 3 or USB software
- Operating Voltage AC110V/AC220V
ChinaCNCzone New 6090 CNC Router 4 Axis with Updated Water Sink Cool System and DSP Mach3 USB CNC Controller for Selection,Price Competitive.
Why add the Sink cooling system ?
It can cool the spindle and protect the machine.
It can cool the spindle and protect the machine.
Avoid the spindle burn out.when you
Can engrave the high hardness or metal
It can improve the efficiency and accuracy of the machine.
What are the main features for this New 6090 CNC Router 4 Axis ?
1.The acceptable material thickness and effective working area of Z axis is 150mm.
2. New added water cooling system, enlarge the working fields and prolong the working life.
3. With 1500W and 2200W Spindle selection
4. 4 axis CNC router
5. USB interface
6. English manual available.
7.Can engrave material such acrylic, brass, wood, aluminum, PCB and so on.
8.Balls crew made it a higher precision.
9.Auto-Checking function, easy to set origin of Z axis
10.With built-in frequency converter in control box
11.It has a broaded base and a thicker screw for larger material working.
12.Limited switches added.
13.From reliable & trustable profesional mini CNC Router manufacturer.
2. New added water cooling system, enlarge the working fields and prolong the working life.
3. With 1500W and 2200W Spindle selection
4. 4 axis CNC router
5. USB interface
6. English manual available.
7.Can engrave material such acrylic, brass, wood, aluminum, PCB and so on.
8.Balls crew made it a higher precision.
9.Auto-Checking function, easy to set origin of Z axis
10.With built-in frequency converter in control box
11.It has a broaded base and a thicker screw for larger material working.
12.Limited switches added.
13.From reliable & trustable profesional mini CNC Router manufacturer.
14.It has three different types of controllers according to users' need.(USB controller box for USB CNC software and parallel port for mach3 cnc software, DSP controller box no need use mach3 software, and mach3 USB controller box for mach3 software.)
What are the advantages of the USB controller box?
1.with the USB CNC cable, you can use the usb CNC software
2.with the parallel port, you can use the mach3 software
3.High performance, lower cost.
1.with the USB CNC cable, you can use the usb CNC software
2.with the parallel port, you can use the mach3 software
3.High performance, lower cost.
What are the advantages of the DSP controller box?
1. with the DSP controller box with independent DSP system,the mini CNC router can work without a computer.
2. After copy the G-code to your SD card, you can insert TF memory card to the TF card slot on the DSP controller box, and then run the G-code directly,
3. G-code files can be directly edited, delete, insert through the DSP controller system.
4.Very easy to operate and suitable for factory application.
5. Select the mini CNC router with DSP controller system, NO need to to use the mach3 software any more.
What are the advantages of the Mach3 USB controller box?
1.For the users who familiar with mach3 software, select this controller, you can use the mach3 software easily through the USB interface directly.
2.High performance, time saving and cost a little higher.
1. with the DSP controller box with independent DSP system,the mini CNC router can work without a computer.
2. After copy the G-code to your SD card, you can insert TF memory card to the TF card slot on the DSP controller box, and then run the G-code directly,
3. G-code files can be directly edited, delete, insert through the DSP controller system.
4.Very easy to operate and suitable for factory application.
5. Select the mini CNC router with DSP controller system, NO need to to use the mach3 software any more.
What are the advantages of the Mach3 USB controller box?
1.For the users who familiar with mach3 software, select this controller, you can use the mach3 software easily through the USB interface directly.
2.High performance, time saving and cost a little higher.
What is the dimension for this CNC 6090 4 axis?
What is the new for the 6090 cnc router 4th axis?
| 6090 cnc router 4 axis Parameters | |
| Effective working travel | 600(X)mm*900(Y)mm*150(Z)mm |
| Shape dimension | 890*1250*670mm |
| Frame materials | Aluminum alloy 6063 and 6061 the unique and dedicated mold extrusion profiles. let counterfeiters dwarfs |
| Axis | 4 Axis version |
| Acceptable material thickness | ≤150mm |
| Driving units | X,Z SFUR1605-DFC7-P0 ball screw, Y SFUR2005-DFC7-P0 ball screw |
| Sliding units X Axis | Dia.30mm chrome plate shafts |
| Sliding units Y Axis | Dia.30mm chrome plate shafts |
| Sliding units Z axis | Dia.16mm chrome plate shafts |
| Stepping motor type | 57 two-phase 3A 150N.cm |
| 4 Axis size and precision | 220(L)*116(W)*105(H)mm, 9KG Transmission ratio: 1:3, 0.6 degree/step, K11 |
| 4Axis maximum clamping diameter | Center height 65mm, 3 Jaw 80mm Chuck, Maximum clamping 125mm ,Tailstock maximum expansion length 50mm ,Maximum clamping weight 30kg |
| Spindle motor | Changlong GDZ80-2.2, 24000RPM, 1500/2200W |
| Principal axis collet | ER20 1-13mm |
| Repeat accuracy | 0.05mm |
| Spindle precision | radial beat acuities 0.03 mm |
| Maximum speed | 0-4000mm/min |
| Control unit | E100S2R2B + JMC542 drive board+1635A 4th Axis drive board + DSP Controller |
| Computer connection | DSP control No need connect computer |
| Command code | G code, or any MACH3 support format file |
| Protection | Emergency stop button |
| Operating Voltage | AC220V/110V |
| Accessories | Pump, Auto checking tool , cutter, banner and so on. |
| Warranty | Two Year |
| Package size | One wooden box package , 121*86*82cm |
| Gross weight | 156KG |
CNC 6090 Mini CNC Engraving Machine 3 Axis
This new DSP CNC 6090 with cooling system can be widely used to engrave wood, acrylic, brass, alumimun,PVC, PCB and so on.
ChinaCNCzone
team always welcome customers from all over the world to visit our
factory, and let us provide the best diffirent models mini CNC routers for users together.
